7-2-2. Setting Up Preview Image
(1) Open the [SETUP – OUTPUT－CLEAN/PREVIEW] (2/2) menu.
OUTPUT : KEYER : PinP1 : PinP2 : DSK : 2/2
PREV OUT: =OFF : =OFF : =OFF : =ON :
(2) Turn F1 to F4 to set whether the KEYER, DSK and PinP images are to be displayed on
the preview image. Then press the push-button to confirm the setting for each.
Item Setting NEXT TRANSITION
KEYER
On-Air/Off-Air
KEYER image on
PREVIEW
PREV
OUT-
KEYER
ON KEYER button ON On-Air Not displayed
ON KEYER button OFF On-Air Displayed
ON KEYER button ON Off-Air Displayed
ON KEYER button OFF Off-Air Not displayed
OFF --- --- Not displayed
Whether the keyer images are displayed on the preview depends on both PREVIEW OUT
setting and KEYER button status in the NEXT TRANSITION section.
Item Setting DSK or PinP image on PREVIEW
PREVIEW OUT - DSK
ON Displayed
OFF Not displayed
PREVIEW OUT - PinP1/2
ON Displayed
OFF Not displayed
7-3. Clean Set Up
The switcher can output the CLEAN via an auxiliary output. Users can also add the KEYER
image to CLEAN. Follow the procedure below to assign the clean video to an AUX output. AUX3
is used in this example
 Sending Clean Signal to AUX Output
(1) Open the [SETUP-OUTPUT-AUX XPT] menu.
(2) Turn F1 to select AUX3.
(3) Turn F2 to select CLN.
OUTPUT :SELECT : XPT : CTRL : ANCI : 1/2
AUX XPT : =AUX3 : =CLN : =ON : =OFF :
 Displaying Keyer Image on Clean
(1) Open the [SETUP – OUTPUT－CLEAN/PREVIEW] (1/2) menu.
(2) Turn F1 to set whether the KEYER image is inserted to the clean image. Then press the
push-button to confirm the setting.
 Displaying PinP1/2 Image on Clean
(1) Open the [SETUP – OUTPUT－CLEAN/PREVIEW] (1/2) menu.
(2) Turn F2 or F3 to set whether the PinP1 or PinP2 image is inserted to the clean image.
Then press the push-button to confirm the setting.
OUTPUT : KEYER : PinP1 : PinP2 : : 1/2
CLEAN : =ON : =OFF : =OFF : :
