6-2. How to Assign Sources to Bus buttons
Primary and optional video inputs, internally generated signals (black, mattes etc) and captured
stills can be freely be assigned to any PGM/PST or KEY/AUX bus buttons using the procedure
below.
(1) Press the MENU button and then press the 7/SETUP button to display the SETUP menu’s
top page.
(2) Turn F1 to select INPUT. Press F1 or the PAGE DOWN button to display the [SETUP –
INPUT] menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :
(3) Turn F1 to select ASSIGN. Press F1 or the PAGE DOWN button to display the [SETUP –
INPUT - ASSIGN] (1/3) menu.
INPUT :BUTTON : SIGNAL NAME :INHIBIT: 1/3
OU ASSGN: =01 : =IN04 =IN04 : =OFF :
(4) Turn F1 to select a bus button under the BUTTON item.
(5) Turn F2 to select the signal to be assigned under the SIGNAL item. Users can also select a
signal by turning F3 under the NAME item. SIGNAL and NAME are linked to each other.
(See section 6-1. "How to Give Name to Source” for more details.)
Submenu Parameter Default Setting range
OU ASSIGN
BUTTON 1
1-12, sft1-sft12 (shifted buttons)
SIGNAL
NAME
IN01
(See the table below)
IN01 (Signal name set in SETUP-INPUT menu)
INHBIT OFF OFF, ON
BUTTON SIGNAL setting Description
01 to 12,
sft01 to sft12
(shifted buttons)
NONE No signal assignment
BLACK Black signal
IN01 to IN04 Video input to rear connectors 1-4
STIL1, STIL2 Still pictures 1 and 2
MATT BUS MATT Color
CLBAR Internally generated color bar signal
SHIFT Shift button function
INA1-INA4
Optional video input to rear connectors of slot A (*1)
(See section 2-4.)
INB1-INB4
Optional video input to rear connectors of slot B (*1)
(See section 2-4.)
(*1) Inputs vary by the type and number of the installed input expansion card.
(6) Users can inhibit specific bus buttons. If INHIBIT is set to ON for a bus button, the selected
bus button for the PGM/PST cannot be selected. This is useful to help reduce the risk of
wrong input selection.
IMPORTANT
The INHIBIT setting has no effect for the KEY/AUX bus. Even if a bus button cannot be
used with the PGM/PST, it can be used for the key source, key insert or AUX output.
