15-3. Selecting Video for Each Split Area
This section shows how to a video source for each split area in the multiviewer screen. This is
done in the [SETUP-OUTPUT-MV SCRN] menu.
(1) Quickly press twice the MV button in the BUS SELECT block to display the [SETUP-
OUTPUT-MV SCRN] menu.
OUTPUT : TYPE :WINDOW :SIGNAL : CHARA : 1/3
MV SCRN : =4 : =01 : =IN01 : = OFF :
(2) Turn F2 to select a channel number (split area) of the split screen under the SCREEN item.
(3) Turn F3 to select video displayed on the split area. The following video sources are
selectable.
Input images IN01-IN12
Internal bus images
BLAK(BLACK), STL1, STL2, MATT, CLBR(Color bar),
PGM, PREV
(4) Repeat (2) and (3) to assign images to the multiviewer channels.
15-4. Adding Titles, On-air Tally and Frame Border
You can set a title to each image and display the on-air tally information. A color border can be
also applied to the split-screen to emphasize channel areas.
15-4-1. Titles
(1) Quickly press twice the MV button in the BUS SELECT block to display the [SETUP-
OUTPUT-MV SCRN] menu.
(2) Turn F2 to select a channel number (split area) of the split screen under the SCREEN
item.
OUTPUT : TYPE :WINDOW :SIGNAL : CHARA : 1/3
MV SCRN : =4 : =01 : =IN01 : =OFF :
(3) Turn F4 to select the type of title display under the CHARA item. (See the table below.)
The texts used for titles are the short name and the long name set in the [SETUP-INPUT-
RENAME] menu. (See section
6-1. "How to Give Name to Sources.")
CHARA setting Description
OFF Displays no title.
SHORT Displays a title within 4 characters.
LONG Displays a title within 8 characters.
Setting Example
In this setting example the multiviewer is set as shown on the right hand side
with the multiviewer settings in the table below
(Names are default settings.)
Channel SIGNAL setting CHARA setting
1 IN01 OFF
2 IN02 SHORT
3 PGM LONG
4 PREV LONG
IN02
PREVIEW
PROGRAM
