10-4. Pattern Modify Example2 (Pattern 117)
This modification example also adds a border effect using Pattern 117. However Pattern 117
has different border settings than Pattern 20. It can use both inside and outside border effects.
(1) Set up KEYER (See section
11. "KEYER and DSK.")
(2) Press KEYER in the NEXT TRANSITION block.
SHORTCUT
Assume that Pattern 117 is registered to 1 in the KEYPAD and DIRECT PATT is set to
ON in the [DIRECT PATTERN] menu, press DIRECT PATT and then press 1 in the
KEYPAD to select 117. Then go to Step (5).
(3) Press WIPE in the TRNSITION TYPE block.
(4) To enter the pattern number in the KEYPAD, press F3, type 117 and press ENT/STORE in
the KEYPAD to select Pattern 117.
(5) Press MENU to the right of the Menu Display (if the light of the button is not turned on), and
then press 4/WIPE in the KEYPAD to display the WIPE menu.
(6) Turn F1 to select BORDER. Press F1 or the PAGE DOWN button.
WIPE :>BORDER >POS/ASP >CROP >SUB EFF
No.117 :>INIT
(7) The [WIPE - BORDER] menu appears. To use the inside border, set the border width under
INSIDE X and Y. To use the outside border, set the border width under OUTSIDE X and Y.
WIPE : INSIDE : OUTSIDE : 1/3
BORDER :X=10 Y=10 :X=5 Y=5 :
(8) Press the PAGE DOWN button to go to PAGE 2. Set the softness for the inside border under
INSIDE X and Y. Set the softness for the outside border under OUTSIDE.
WIPE : INSIDE :OUTSIDE: : 2/3
BDR SOFT:X=3 Y=3 : =2 : :
(9) Press the PAGE DOWN button to go to PAGE 3. Turn F4 to select a border color from eight
standard colors. Press F4 to apply the selected color. If you want to adjust the selected color
or set the color by entering HSL values, turn F1, F2 and F3 to adjust values or press F1, F2
and F3, enter a value in the Keypad and then press ENT/STORE in the Keypad. Users can
also set these three parameters in the JOYSTICK block. (See section 4-2-4. "Changing
Settings or Values by Using the Joystick.")
WIPE : BORDER COLOR :RECALL : 3/3
BDR COL :S=66.3 L=5.4 H=3.5 : >BLUE :
