20-4-2. Ethernet
The Ethernet connection is used for connecting HVS-30GUI, the control software connection
or transferring image data. (See section
20-5. "Image Data Transfer.")
Connecting to LAN
Use the twisted pair, Category 5 (UTP) cable (straight- through type) to connect the main unit
(MU) to LAN. If connecting the MU to a PC directly, use the cross-connect type cable.
IP Address, Net mask and Default Gateway Setting
Open the [SETUP-SYSTEM-ETHERNET] menu. The default settings for IP address, Net
mask and Default Gateway are as shown below.
SYSTEM : IP ADDRESS : : 1/4
ETHERNET: =192.168.000.010 : :
SYSTEM : NET MASK : : 2/4
ETHERNET: =255.255.255.000 : :
SYSTEM : DEFAULT GATEWAY : : 3/4
ETHERNET: =192.168.001.001 :
Changing IP Address, Net mask and Default Gateway
(1) Open the IP address page (or the net mask page).
(2) Press F1.
(3) The first octet (192 in the IP address example above) will be highlighted.
(4) Turn F1 to change the number.
(5) Press F1.
(6) The second octet (168 in the IP address example above) will be highlighted.
(7) Repeat (4) and (5) to change the IP address.
(8) Reboot the main unit. (See section
19-1. "Rebooting System."）
IMPORTANT
You should consult your network administrator before connecting the HVS-300 series
to the LAN.
MAC Address
The MAC address of the network card is displayed in PAGE4.
SYSTEM : MAC ADDRESS : : 4/4
ETHERNET: 00-00-00-00-00-00 : :
