20-3. Editor Control (Option)
The switcher can be controlled from an editor. See section 20-3-1."Editor Control Settings" for
controlling the editor and section
20-3-2 "Connection Settings with Editor (EDITOR port setting)"
for editor connection.
The HVS-30ED software option is required for editor control.
20-3-1. Editor Control Settings
(1) Open the [SETUP-EXT I/F-EDITOR] menu.
SETUP :>RS-422 >EDITOR >TLY COL >GPI I/O
EXT I/F :>TALLY1 >TALLY2
(2) Select a protocol at TYPE between BVS3K and GVG100.
(3) Set ENABLE to ON to enable the editor control. (The Editor Control On/Off function can
be assigned to USER button. See section
5. "USER Button.")
EXT I/F : TYPE :ENABLE :SELECT : WIPE : 1/2
EDITOR : =BVS3K: =ON : =ME : =NORML:
(4) If BVS3K (BVS-3000) is used, the bus to be controlled from the editor must be specified.
Refer to the table below to set the bus under the SELECT item. If PREV, PREV ON or ALL
is set, AUX1 will be the edit preview bus and whose crosspoint number is 35. Set your
editor accordingly.
Setting Description
ME Controls the M/E bus when ENABLE is ON.
PREV Controls the preview bus when ENABLE is ON.
ALL Controls both M/E bus and preview bus when ENABLE is ON.
ME ON
Always controls the M/E bus regardless of ENABLE setting.
Controls both M/E bus and preview bus when ENABLE is ON.
PREV ON
Always controls the preview bus regardless of ENABLE setting.
Controls both M/E bus and preview bus when ENABLE is ON.
(5) If GVG-100 is used, select the pattern control mode between two below at WIPE.
Setting Description
NORMAL
Same wipe pattern numbers (0-99) as in the switcher are used in the editor.
(default setting)
LIST
Ten wipe patterns saved to Direct Pattern memory are used in the editor as
Direct Pattern No.90-99. (GVG-100 only)
(6) Press the PAGE DOWN button to go to PAGE2.
EXT I/F :XPT CTL:WIP CTL:KEY CTL: : 2/2
EDITOR : =INPUT: =ON : =ON : :
