11-3-2. KEY INSERT MATT
In addition to the bus matt signal, the internally generate MATT can be used as key fill.
KEY INSERT MATT is dedicated matte signal for DSK and KEYER and it is not same as
BUS MATT. The different colors can be set in KEY INSERT MATT for KEYER and DSK.
(1) Set up a Bus Key, then press F2 in the [DSK - INS/SRC] menu to set INSERT to InMat
(Insert Matt).
DSK : TYPE :INSERT :SOURCE :INVERT : 1/3
INS/SRC : =BUS : >InMat: =IN02 : =OFF :
(2) Press the PAGE DOWN button to go to PAGE3.
(3)Turn F4 and select a color from eight standard colors. To use a different color, turn F1, F2,
and F3 to adjust the color.
DSK : MATT COLOR :RECALL : 3/3
INS MATT:S=67.3 L=15.8 H=257.5: >RED :
Key Links cannot be applied to KEY MATT.
11-4. Adjusting Key Signal
Clip and Gain allows users to adjust the key signal and its composition over the background.
The transparency of the Keyer can also be adjusted.
(1) Double-click DSK (or KEYER) in BUS SELECT, and display the [DSK SETUP] menu.
(2) Turn F1 to select INS/SRC, and press F1 or the PAGE DOWN button.
DSK :>INS/SRC >EDGE >MASK
SETUP :>POS/SIZ >BORDER >SUB EFF >INIT
(3) The [DSK - INS/SRC] menu is displayed. Press the PAGE DOWN button to go to PAGE2.
DSK : GAIN : CLIP :TRANSP :FAM : 2/3
PROC AMP: =1.0 : =0.0 : =0.0 : =OFF :
(4) Turn F1 to adjust GAIN
(5) Turn F2 to adjust CLIP for adjusting Keyer.
(6) Turn F3 to set the transparency of Keyer. Increasing the value makes the Keyer more
transparent.
