IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
116 TIMS MVP™ Setup and Configuration Guide
In the next example, you can see the contrast between the white text and black background is
blurred. Black and white pixels are mixed which indicates that it is poorly aligned.
Figure 25: Example of text that needs a phase delay adjustment
It is recommended that you run Auto… first to see if this fixes the phase delay for the
video image. If this does not you need to the phase delay but entering values in the
Phase Delay text box or using the up/down arrows to change the value.
Notice how there is less of
delineation between the black
and white pixels.
