IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
TIMS MVP™ Setup and Configuration Guide 123
In the next example, the image width is too wide.
Figure 32: Example of video image that is too wide
To adjust the video image, decrease the image width to fit into the left and right
edges.
When the image is too large,
the left edge is clipped and
the right edge has a blank
area.
