IDEA Auto-SYNC with RGB/VGA/DVI Analog Video
122 TIMS MVP™ Setup and Configuration Guide
In the next example, the image width is too small and needs to increase the width to
the right edge.
Figure 31: Example of video image that is not wide enough
To adjust the video image, increase the image width to widen the image to the right
edge.
The image is clipped
on the right side. The
image needs to be
widened to the
right edge.
