Using Auto-SYNC for Digital Input Connections
TIMS MVP™ Setup and Configuration Guide 209
In the next example, the video image is too large and is clipped on its left edge.
Figure 109: Example of framing values too large
To adjust the image, decrease the HBS value to move the image to the right. This
adjustment will result in the whole image displaying without a clipped left edge.
Notice that the left edge is
clipped. This is because the
image is too large.
