Using Auto-SYNC for Digital Input Connections
TIMS MVP™ Setup and Configuration Guide 211
In the next example, the image width is too small and needs to increase the width to the right
edge.
Figure 111: Example of video image that is not wide enough
To adjust the video image, increase the image width to widen the image to the right edge.
The image is clipped
on the right side. The
image needs to be
widened to the
right edge.
