System Config HA
FortiGate Version 3.0 MR4 Administration Guide
01-30004-0203-20070102 123
Figure 64: Example FortiGate-5001SX cluster members list
If virtual domains are enabled, you can display the cluster members list to view
the status of the operating virtual clusters. The virtual cluster members list shows
the status of both virtual clusters including the virtual domains added to each
virtual cluster.
To display the virtual cluster members list for an operating cluster log in as the
global admin administrator and go to System > Config > HA.
Figure 65: Example FortiGate-5001SX virtual cluster members list
View HA Statistics Display the serial number, status, and monitor information for each
cluster unit. See “Viewing HA statistics” on page 125.
Up and down arrows Change the order in which cluster members are listed. The
operation of the cluster or of the units in the cluster are not
affected. All that changes is the order in which cluster units are
displayed on the cluster members list.
Disconnect from Cluster
Edit
Download Debug Log
Up and Down
Arrows
Disconnect from Cluster
Up and Down
Arrows
Edit
Download Debug Log
