FortiGate Version 3.0 MR4 Administration Guide
18 01-30004-0203-20070102
Introducing the FortiGate units Introduction
Introducing the FortiGate units
All FortiGate Unified Threat Management Systems from the FortiGate-50B to the
FortiGate-5000 series deliver similar SOHO or enterprise-class network-based
antivirus, content filtering, firewall, VPN, and network-based intrusion
detection/prevention features.
FortiGate-5000 series chassis
The FortiGate-5000 series Security Systems are chassis-based systems that
MSSPs and large enterprises can use to provide subscriber security services
such as firewall, VPN, antivirus protection, spam filtering, web filtering and
intrusion prevention (IPS). The wide variety of system configurations available
with FortiGate-5000 series provide flexibility to meet the changing needs of
growing high performance networks. The FortiGate-5000 series chassis support
multiple hot-swappable FortiGate-5000 series modules and power supplies. This
modular approach provides a scalable, high-performance and failure-proof
solution.
FortiGate-5140 chassis
You can install up to 14 FortiGate-5000 series modules in the 14 slots of the
FortiGate-5140 ATCA chassis. The FortiGate-5140 is a 12U chassis that contains
two redundant hot swappable DC power entry modules that connect to -48 VDC
Data Center DC power. The FortiGate-5140 chassis also includes three hot
swappable cooling fan trays.
FortiGate-5050 chassis
You can install up to five FortiGate-5000 series modules in the five slots of the
FortiGate-5050 ATCA chassis. The FortiGate-5050 is a 5U chassis that contains
two redundant DC power connections that connect to -48 VDC Data Center DC
power. The FortiGate-5050 chassis also includes a hot swappable cooling fan
tray.
FAN TRAY FAN TRAYFAN TRAY
1311975312468101214
5140
