Web-based manager pages
The web-based manager interface consists of a menu and pages, many of which
have multiple tabs. When you select a menu item, such as System, it expands to
reveal a submenu. When you select one of the submenu items, the associated
page opens at its first tab. To view a different tab, select the tab.
The procedures in this manual direct you to a page by specifying the menu item,
the submenu item and the tab, like this:
1 Go to System > Network > Interface.
Figure 5: Parts of the web-based manager (shown for the FortiGate-50B)
Web-based manager menu
The menu provides access to configuration options for all major features of the
FortiGate unit.
Tabs
Menu
Page
Button bar
System Configure system facilities, such as network interfaces, virtual domains,
DHCP services, High Availability (HA), system time and set system
options.
Router Configure FortiGate static and dynamic routing.
Firewall Configure firewall policies and protection profiles that apply network
protection features. Also configure virtual IP addresses and IP pools.
VPN Configure IPSec, SSL, and PPTP virtual private networking.
User Configure user accounts for use with firewall policies that require user
authentication. Also configure external authentication servers such as
RADIUS, LDAP, and Windows AD.
AntiVirus Configure antivirus protection.
Intrusion
Protection
Configure the FortiGate Intrusion Protection System (IPS).
Web Filter Configure web filtering.
