FortiGate Version 3.0 MR4 Administration Guide
402 01-30004-0203-20070102
Statistics IM, P2P & VoIP
Viewing statistics by protocol
The protocol tab provides detailed statistics for individual IM protocols.
To view protocol statistics, go to IM/P2P > Statistics > Protocol.
You can log IM chat information and the limitations placed on it, by enabling
Archive full IM chat info to FortiAnalyzer in the protection profile.
Figure 271:IM statistics by Protocol
The IM/P2P Protocol tab has the following icons and features:
Chat For each IM protocol, the following chat information is listed:
• Total Chat Sessions
• Total Messages.
File Transfers For each IM protocol, the following file transfer information is
listed:
(File transfers) Since Last Reset and (File transfers) Blocked.
Voice Chat For each IM protocol, the following voice chat information is listed:
• (Voice chats) Since Last Reset
• (Voice chats) Blocked.
P2P Usage For each P2P protocol, the following usage information is listed:
• Total Bytes transferred
• Average Bandwidth.
VoIP Usage For SIP and SCCP protocol, the following information is listed:
• Active Sessions (phones connected)
• Total calls (since last reset)
• Calls failed/Dropped
• Calls Succeeded
Automatic Refresh
Interval
Select the automatic refresh interval for statistics. Set the interval
from none to 30 seconds.
Protocol Select the protocol for which statistics are to be displayed: AIM,
ICQ, MSN, or Yahoo.
