Router Monitor Displaying routing information
FortiGate Version 3.0 MR4 Administration Guide
01-30004-0203-20070102 209
Router Monitor
This section explains how to interpret the Routing Monitor list. The list displays the
entries in the FortiGate routing table.
The following topics are included in this section:
Displaying routing information
Searching the FortiGate routing table
Displaying routing information
By default, all routes are displayed in the Routing Monitor list. The default static
route is defined as 0.0.0.0/0, which matches the destination IP address of “any/all”
packets.
To display the routes in the routing table, go to Router > Monitor.
Figure 116 shows the Routing Monitor list belonging to a FortiGate unit that has
interfaces named “port1”, “port4”, and “lan”. The names of the interfaces on your
FortiGate unit may be different.
Figure 116:Routing Monitor list
