System Chassis (FortiGate-5000 series) Blades (FortiGate-5000 chassis slots)
FortiGate Version 3.0 MR4 Administration Guide
01-30004-0203-20070102 175
Temperature Indicates if the temperature sensors for the module in each slot are
detecting a temperature within an acceptable range. Good indicates
that all monitored temperatures are within acceptable ranges. Alarm
indicates that a monitored temperature is too high (usually about
75°C) or too low (below 10°C).
You can mouse over the temperature indicator to view the
temperatures being read by each sensor on the module. The mouse
over display includes the name of the temperature sensor and the
temperature reading.
The temperatures that are displayed depend on the FortiGate or
FortiSwitch module. For example:
For FortiGate-5005FA2 modules:
• Incoming Air-Flow: 37°C
• CPU Board Temp: 49°C
• CPU1 Temp: 65°C
• CPU2 Temp: 66°C
For FortiGate-5001SX and FortiGate-5001FA2 modules:
• TEMP1: 37°C
• TEMP2: 30°C
And for FortiSwitch-5003 modules:
• Baseboard Temp: 35°C
• Board (BRD) Top Temp: 33°C
• BRD Bottom Temp: 33°C
• BRD Center Temp: 38°C
Voltage Indicates if the voltage sensors for the module in each slot are
detecting a voltage within an acceptable range. Good indicates that all
monitored voltages are within acceptable ranges. Alarm indicates that
a monitored voltage is too high or too low.
You can mouse over the voltage indicator for each slot to view the
voltages being read by each sensor. The information displayed for
each sensor includes the design voltage (for example 3.3V) and the
actual measured voltage (for example, 3.288V). The acceptable
voltage range depends on the sensor.
The voltages that are displayed are different for different
FortiGate-5000 series modules. For example:
For FortiGate-5005FA2 modules:
• CPU1 Voltage: 1.1956V
• CPU1 Voltage: 1.1858V
• +5.0V: 4.851V
• +3.3V: 3.321V
• +2.5V CPU 1: 2.5376V
• +2.5V CPU 2: 2.5498V
• +1.2V 1: 1.1956V
• +1.2V 2: 1.2054V
For FortiGate-5001SX and FortiGate-5001FA2 modules:
• 5V: 5.0764V
• 3.3V: 3.4884V
• 2.5V: 2.534V
• 1.8V: 1.8236V
• 1.5V: 1.5326V
And for FortiSwitch-5003 modules:
• +1.5V: 1.521V
• +2V: 1.989V
• +2.5V: 2.4921V
• +3.3V: 3.3024V
• +3.3VSB: 3.3712V
• +5VSB: 5.096V
• +12V: 12.096V
