Broadcast
181
Fax
4
3
Select [Manual Send] from the drop-down
menu.
4
Use the keyboard shown in the touch screen
to enter numbers in the following format.
Note • You can specify up to 20 locations for relay recipients.
F Code Method
When the machine is an initiating station, you can perform Relay Broadcast by
registering the relay station’s F code and password (if necessary) to the machine.
When the machine is a relay station, you can perform Relay Broadcast by registering
the machine’s F code and password (if necessary) to an initiating station.
Important • When performing Relay Broadcast with the F Code method, you can use a password if you
set a receive password for the relay station.
Note • When performing Relay Broadcast with machines of this model, we recommend using the
fax signal method.
• When using a machine of a different model as a relay station, confirm the F Code (sub-
address) and password of the target recipient machine.
When using the machine as a relay station, the F Code that is transmitted to the
initiating station is as follows.
îš„Relay Broadcast
The number of digits of the relay station ID:
1: When the relay station IDs and address numbers are two digits
2: When the relay station IDs and address numbers are three digits
îš„Print Directive
Printing/not printing at the relay station
1: Printing at the relay station
0: Not printing at the relay station
îš„Relay Station ID
An address number for an initiating station registered at the relay station
When the relay station ID is set, the initiating station is notified of the results of a Relay
Broadcast.
When the relay station ID is "00" or "000", the initiating station is not notified of the
results of a Relay Broadcast.
Relay Broadcast Print
Directive
Relay
Station ID
Address
Number
Address
Number
Address
Number ....
Up to 20 digits
To Next Page
