îš„Address Number
The address number assigned to the relay recipient
The following shows an example of F Code that indicates printing at the relay station,
notifying the initiating station (100) of the results, and performing Relay Broadcast to
relay recipients (200, 201, 202 and 203).
F Code Example: 21100200201202203
1
Select the [Fax/Internet Fax Options] tab to
display the [Fax/Internet Fax Options]
screen.
2
Select [F Code].
3
Select [On].
4
Enter the F Code with the numeric keypad.
Note • You can enter up to 20 digits for the F
Code.
5
If necessary, enter the password using the
numeric keypad and select [Next].
Important • You can enter up to 20 digits for the password.
Remote Relay Broadcast (Performing Relay Broadcast to Remote
Locations)
The Remote Relay Broadcast feature combines two or more Relay Broadcast
operations and use Broadcast Send.
This feature is more economical than Relay Broadcast in transmitting documents to
multiple remote machines.
Note • Multiple Relay Broadcast can be performed from a secondary relay station.
There are three Relay Broadcast methods.
îš„Fax Signal Method
This method employs a Fuji Xerox proprietary communication procedure that is only for
use with specific machines that have the Relay Broadcast feature. The G3 is available.
îš„DTMF Method
G3 fax machines that support Manual Send can make Remote Relay Broadcast for the
machine.
îš„F Code Method
This method can be used among machines that have the F Code and the Relay
Broadcast features. The G3 is available.
Fax Signal Method
Register the following information in the address numbers of initiating stations and relay
stations in advance.
For information on how to register address numbers, refer to "5 Tools" > "Setup" > "Add Address Book
Entry" in the Administrator Guide.
