Replacing Consumables
231
Maintenance
12
4 Unpack a new toner cartridge, and shake it
lightly up/down, and left/right 10 times.
Important • Do not touch the shutter.
5 Orient the toner cartridge with the arrow (K)
facing up, and insert it as far as it will go.
6 Close the front cover.
Note • If the front cover is not completely closed, an
error code will appear and the machine will
remain paused.
Replacing the Waste Toner Container [R5]
The waste toner container holds used toner. The following messages are displayed on the
touch screen according to the status of the waste toner container. Follow the messages.
Message
Remaining Page
Yield
*
Machine Status and Action
Waste Toner Container
Life Over
Open the Front
Cover.Then, replace the
Waste Toner Container
[R5].
1000 pages The waste toner container is near the end of
its life. Prepare a new one.
To Next Page
