AC Input Voltage Available modes
AC 100 V - 127 V No redundant PSU support (mode: two fixed PSUs)
If AC input total maximum power consumption of
system >1235
W
Redundant PSU support (mode: 1+1 PSU)
If AC input total maximum power consumption of
system <= 1235 W
AC 200 V - 240 V No redundant PSU support (mode: two fixed PSUs)
If AC input total maximum power consumption of
system >1810 W
Redundant PSU support (mode: 1+1 PSU)
If AC input total maximum power consumption of
system <=1810 W
To serve as a redundant power supply support: If one PSU fails, the second
PSU in the redundant configuration ensures operation can continue
uninterrupted and the defective PSU can be replaced during operation (hot-
plug).
T
o serve as non-redundant power supply support: If one PSU fails, the system
may run with CPUs power capping (performance limited) condition to operate
or may shutdown triggered by PSU that depends on actual power loading.
Delta Electronic 100-240 V Output Power 2200 Watt (AC input high line) /
1000 Watt (AC input low line)
Assembly rules
–
Only use the allowed PSU configuration with two hot-plug PSUs (1600 W).
–
For a redundant power supply configuration you need always two PSUs with
the same power class.
Power supply unit (PSU)
122 Upgrade and Maintenance Manual RX4770 M5
