Fujitsu PRIMERGY RX4770 M5 User Manual

Concluding steps
▶
Install riser module 3/4, see "Installing the riser module 3/4 and 6/7" on
page
62.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
▶
Configure the new MAC address in the OS, if you have no VIOM
(ServerView Virtual-IO Manager) installed.
If you have VIOM installed, it is not necessary to configure the MAC
address.
This is virtualized by VIOM.
▶
Inform the customer about new MAC addresses. For more information, see
"Basic information" on page 110.
▶
"Updating the NIC configuration file in a Linux and VMware environment" on
page 107.
▶
"Configuring LAN teaming" on page 116.
9.5.3 Removing an OCP module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
– Forceps
–
Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
Remove riser module 3/4, see "Removing the riser module 3/4 and 6/7" on
page 61.
Expansion cards and backup units
RX4770 M5 Upgrade and Maintenance Manual 185
