Concluding steps
▶
Install the corresponding riser module, see "Handling riser modules" on
page
60.
▶
"Reassembling" on page 53.
▶
Connect all external cables to the replaced expansion cards.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
▶
"Enabling replaced components in the BIOS" on page 102.
▶
If applicable, "Updating expansion card firmware" on page 93.
▶
If applicable, "Enabling the boot watchdog" on page 101.
▶
"Resuming BitLocker functionality" on page 108.
9.7.6 Installing a TFM
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Different TFM kits are available, depending on the RAID controller.
Preliminary steps
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
Installing the TFM
▶
If applicable, remove the expansion card, see "Removing the expansion
card" on page 209.
Expansion cards and backup units
216 Upgrade and Maintenance Manual RX4770 M5
