Concluding steps
â–¶
Install the bottom system board, see "Installing the new bottom system
board" on page
365.
â–¶
Install the air duct on the bottom system board, see "Installing the CPU air
duct" on page 74.
â–¶
"Installing the top system board holder" on page 79.
â–¶
"Installing the fan cage" on page 71.
â–¶
Install the air duct on the top system board, see "Installing the CPU air duct"
on page 74.
â–¶
Install all riser modules and the RAID card, see "Expansion cards and riser
cards" on page 190.
â–¶
If applicable, install the OCP module, see "Installing an OCP module" on
page 184.
â–¶
"Reassembling" on page 53.
â–¶
"Installing the server in the rack" on page 55.
â–¶
"Connecting the power cord (AC PSU)" on page 58.
â–¶
"Switching on the server" on page 59.
14.4.5 Replacing the TPM
Field Replaceable Unit
(FRU)
Hardware: 40 minutes
System board and components
324 Upgrade and Maintenance Manual RX4770 M5
