4.10 Handling the fan cage
4.10.1
Removing the fan cage
Figure 22: Releasing a hot-plug fan module
â–¶
Pull up each hot-plug fan module by the green strap to release it from the
system board.
Basic hardware procedures
RX4770 M5 Upgrade and Maintenance Manual 69
