Figure 115: Connecting the FBU cable
▶
Connect the FBU cable to the TFM.
▶
Install the expansion card, see "Installing the expansion card" on page
192.
Concluding steps
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
9.7.7 Removing a TFM
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Expansion cards and backup units
RX4770 M5 Upgrade and Maintenance Manual 219
