Push the ODD dummy cover inward until it engages at the right side.
Concluding steps
▶
"Installing the fan cage" on page
71.
▶
Install the air duct on the top system board, see "Installing the CPU air duct"
on page 74.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
▶
"Resuming BitLocker functionality" on page 108.
▶
"Reconfiguring the backup software solution" on page 95.
12.1.5 Replacing the ODD
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
▶
"Locating the defective server" on page
43.
▶
"Removing backup and optical disk media" on page 88.
▶
"Suspending BitLocker functionality" on page 85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
Accessible drives
300 Upgrade and Maintenance Manual RX4770 M5
