12.1.4 Removing the ODD
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
▶
"Removing backup and optical disk media" on page
88.
▶
"Suspending BitLocker functionality" on page 85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
▶
"Removing the fan cage" on page 69.
Accessible drives
RX4770 M5 Upgrade and Maintenance Manual 297
