Fujitsu PRIMERGY RX4770 M5 - Replacing the Dual Microsd 64 GB Enterprise

Concluding steps
▶
Install the riser module 3/4, see "Installing the riser module 3/4 and 6/7" on
page
62.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
14.7.4 Replacing the Dual microSD 64GB Enterprise
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
▶
"Locating the defective server" on page
43.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
Remove the riser module 3/4, see "Removing the riser module 3/4 and 6/7"
on page 61.
System board and components
RX4770 M5 Upgrade and Maintenance Manual 349
