Storing the ODD latch
Figure 159: Storing ODD latch
The ODD latch is fastened with two screws on the bottom plate of the ODD
bay
.
▶
Remove the two screws.
▶
Remove the ODD latch from its storing location.
12.1.3 Installing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Preliminary steps
▶
"Suspending BitLocker functionality" on page
85.
▶
"Shutting down the server" on page 45.
Accessible drives
