Numbering of the fan modules
6
5
2
3
4
1
Figure 68: Numbering of the fan modules
1 fan 1/2
2
fan 3/4
3 fan 5/6
4 fan 7/8
5 fan 9/10
6 fan 11/12
8.3 Replacing a defective fan module
Customer Replaceable
Unit (CRU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page
43.
▶
"Getting access to the component" on page 47.
Fans
164 Upgrade and Maintenance Manual RX4770 M5
