Figure 233: Applying the thermal paste
▶
Apply a small point-shaped amount of thermal paste (1.0 gram, see
description above) to the center of the CPU surface as shown.
CAUTION
▶
Do not mix different types of thermal paste.
15.4 Replacing memory modules
For general information on the main memory, see "Main memory" on
page 239.
In this section only the special handling of the memory modules is
described, if LC is used.
For Japan:
Adhesive memory pads are attached to memory modules in advance.
Liquid cooling (LC)
396 Upgrade and Maintenance Manual RX4770 M5
