Position HDD install order
ServerView RAID Manager
display name
[7] HDD7 Vendor Product (7)
[8] HDD8 Vendor Product (8)
[9] HDD9 Vendor Product (9)
[10] HDD10 Vendor Product (10)
[11] HDD11 Vendor Product (11)
[12] HDD12 Vendor Product (12)
[13] HDD13 Vendor Product (13)
[14] HDD14 Vendor Product (14)
[15] HDD15 Vendor Product (15)
7.4.1.2 Configuration with up to 12 SAS/SATA/PCIe SSD modules
CPU 1 does not support PCIe SSD, so the first four slots are empty. But
it is possible to install SAS/SA
TA HDD/SSD.
Figure 54: Configuration with up to 12 SAS/SATA/PCIe SSD modules
Position HDD install order
PCIe SSD
install
order
ServerView RAID
Manager display name
[0] dummy dummy
[1] dummy dummy
[2] dummy dummy
Hard disk drive (HDD) / solid state disk (SSD)
RX4770 M5 Upgrade and Maintenance Manual 143
