Fujitsu PRIMERGY RX4770 M5 User Manual

Concluding steps
For M.2 SSD with 1
10 mm
▶
"Installing the top system board holder" on page 79.
▶
If applicable, "Installing the riser module" on page 65.
▶
"Installing the riser module 3/4 and 6/7" on page 62.
▶
"Installing the fan cage" on page 71.
▶
Install the air duct on the top system board, see "Installing the CPU air duct"
on page 74.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
For M.2 SSD with 42 and 80 mm
▶
If applicable, "Installing the riser module" on page 65.
▶
"Installing the riser module 3/4 and 6/7" on page 62.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
14.6.4 Replacing the M.2 SSD
For M.2 SSD with 110 mm
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for housing cover)
–
Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
System board and components
RX4770 M5 Upgrade and Maintenance Manual 341
