14.6.2 Installing the M.2 SSD
For M.2 SSD with 1
10 mm
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for housing cover)
–
Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
For M.2 SSD with 42 and 80 mm
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for housing cover)
–
Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
Preliminary steps
For M.2 SSD with 1
10 mm
â–¶
"Shutting down the server" on page 45.
â–¶
"Disconnecting the power cord" on page 46.
â–¶
"Removing the server from the rack" on page 49.
â–¶
"Getting access to the component" on page 47.
â–¶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
â–¶
"Removing the riser module 3/4 and 6/7" on page 61.
â–¶
If an expansion card is installed in slot 5, see "Removing the riser module"
on page 64.
â–¶
"Removing the fan cage" on page 69.
System board and components
334 Upgrade and Maintenance Manual RX4770 M5
