"Removing the top system board holder" on page
74.
For M.2 SSD with 42 and 80 mm
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the riser module 3/4 and 6/7" on page 61
▶
If an expansion card is installed in slot 5, see "Removing the riser module"
on page 64.
Installing the M.2 SSD
CAUTION
An M.2 SSD in M.2 slot 2 is not recognized, if M.2 slot 1 is free.
▶
The M.2 slot 1 must be equipped first.
Each M.2 SSD needs one hexagon stand-off for fastening. To support
dif
ferent length of M.2 SSD, several nuts are on the system board
indicating the positions for fastening the M.2 SSD.
If no M.2 SSD has been installed before:
▶
Remove the screw (see orange circles in Figure 187).
If the hexagon stand-off is unscrewed as well, remove the screw from
the hexagon stand-of
f.
▶
Install the hexagon stand-of
f on the right position depending on the length of
the M.2 SSD.
System board and components
RX4770 M5 Upgrade and Maintenance Manual 335
