13 Front panel
13.1
Safety notes
CAUTION
▶
When inserting the front panel module into the server, ensure not to
pinch or strain any connected cables.
▶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity
. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic-sensitive devices (ESDs).
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
▶
For more information, see "Important information" on page 29.
13.2 Basic information
In case of a defective ambient temperature sensor
, please replace the front
panel.
Front panel module
The front panel module consists of a holder, front panel board, ID card, 2x
USB3.0, and a front VGA.
13.3 Front panel module
13.3.1 Replacing the front panel module
Field Replaceable Unit
(FRU)
Hardware: 35 minutes
Software: 5 minutes
RX4770 M5 Upgrade and Maintenance Manual 303
