For M.2 SSD with 42 and 80 mm
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for housing cover)
–
Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
Preliminary steps
If maintenance work involving parts replacement and expansion is
performed in an environment where Windows Server is installed,
reauthentication of Windows Server may be necessary
. If re-
authentication is required, inform the customers or system engineer.
For M.2 SSD with 110 mm
▶
"Locating the defective server" on page
43.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Removing the server from the rack" on page 49.
▶
"Getting access to the component" on page 47.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
▶
"Removing the riser module 3/4 and 6/7" on page 61.
▶
If an expansion card is installed in slot 5, see "Removing the riser module"
on page 64.
▶
"Removing the fan cage" on page 69.
▶
"Removing the top system board holder" on page 74.
For M.2 SSD with 42 and 80 mm
▶
"Shutting down the server" on page 45.
System board and components
342 Upgrade and Maintenance Manual RX4770 M5
