Figure 163: Connecting the cables to the ODD
▶
Connect the SA
TA ODD cable to the ODD.
The SATA ODD cable is pre-installed.
Concluding steps
▶
"Installing the fan cage" on page
71.
▶
Install the air duct on the top system board, see "Installing the CPU air duct"
on page 74.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
"Switching on the server" on page 59.
▶
"Resuming BitLocker functionality" on page 108.
Accessible drives
296 Upgrade and Maintenance Manual RX4770 M5
