Fujitsu PRIMERGY RX4770 M5 User Manual

▶
Disengage the ODD latch.
▶
Pull the ODD out of the bay
.
Figure 166: Removing the ODD latch from the ODD
▶
Remove the two screws (see circles).
▶
Remove the ODD latch.
▶
If no new ODD will be installed, fasten the ODD latch with two screws to the
bottom plate of the ODD bay
, see "Storing the ODD latch".
Installing the dummy cover
Figure 167: Installing the dummy cover
Accessible drives
RX4770 M5 Upgrade and Maintenance Manual 299
