Tools: – Phillips PH2 / (+) No. 2 screw driver (for housing cover)
Removing the bottom system board:
–
Phillips PH2 / (+) No. 2 screw driver
Replacing the TPM:
– Bit screw driver
–
TPM bit insert
(*)
– flat nose pliers
–
thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later
.
Preliminary steps
▶
"Locating the defective server" on page
43.
▶
"Suspending BitLocker functionality" on page 85.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Removing the server from the rack" on page 49.
▶
"Getting access to the component" on page 47.
▶
Remove all riser modules and the RAID card, see "Expansion cards and
riser cards" on page 190.
▶
Remove the air duct from the top system board, see "Removing the CPU
air duct" on page 72.
System board and components
RX4770 M5 Upgrade and Maintenance Manual 325
