Fujitsu PRIMERGY RX4770 M5 - Page 326

▶
"Removing the fan cage" on page
69.
▶
If applicable, remove the OCP module, see "Removing the OCP module"
on page 186.
▶
"Removing the top system board holder" on page 74.
▶
Remove the air duct from the bottom system board, see "Removing the
CPU air duct" on page 72.
▶
Remove the bottom system board, see "Removing the defective bottom
system board" on page 362.
Removing the defective TPM
▶
Remove the TPM, see "Removing the TPM" on page 319.
▶
Leave the TPM spacer on the bottom system board when removing the
defective TPM.
Installing the new TPM
The TPM spacer is already present on the system board.
▶
Install the TPM, see "Installing the TPM" on page
316.
Concluding steps
▶
Install the bottom system board, see "Installing the new bottom system
board" on page 365.
▶
Install the air duct on the bottom system board, see "Installing the CPU air
duct" on page 74.
▶
"Installing the top system board holder" on page 79.
▶
If applicable, install the OCP module, see "Installing an OCP module" on
page 184.
▶
"Installing the fan cage" on page 71.
▶
Install the air duct on the system board, see "Installing the CPU air duct" on
page 74.
System board and components
326 Upgrade and Maintenance Manual RX4770 M5
