The configuration with up to 12 HDD/SSD modules and 4 PCIe SSDs
works with a 2 or 4 CPU (each CPU with <= 165 W) configuration or
Liquid Cooling configuration. In a 2 CPU configuration only the bays 12
to 15 support PCIe SSDs.
If you use 4 CPUs with > 165 W air cooling system, you can only use
equipped 8 HDD/SSD modules as SAS/SA
TA or PCIe configuration.
For information on RAID controllers controlling the HDD/SSD modules,
see "Expansion cards and backup units" on page
167.
Note on life time of an SSD
To monitor the life time of an SSD correctly, please ensure to use the
latest RAID Manager version.
The latest RAID Manager version is available from the Fujitsu support internet
pages at:
https://ts.fujitsu.com/support/
▶
Select Software.
▶
Select ServerV
iew.
▶
Select Operation.
▶
Select RAID Management.
For Japan:
The latest RAID Manager version is available at:
https://www.fujitsu.com/jp/products/computing/servers/primergy/
▶
Click 「ダウンロード」.
▶
Click 「ダウンロード検索」.
▶
Click on your PRIMERGY system to select it.
▶
Click 「RAID」 and click 「検索開始」.
In the next screen, you can find ServerView RAID Manager.
Hard disk drive (HDD) / solid state disk (SSD)
