Tools:
– Forceps
–
Phillips PH2 / (+) No. 2 screw driver (for housing cover)
PLAN EM 2x 10 GB SFP+ OCP Interface Intel
®
OCP X527-DA2
Figure 89: OCP module with 2 slots
▶
Install the SFP+transceiver modules, see "Installing SFP+ transceiver
modules" on page 174.
▶
Install the OCP modules, see "Installing an OCP module" on page 184.
Expansion cards and backup units
RX4770 M5 Upgrade and Maintenance Manual 189
