Fujitsu PRIMERGY RX4770 M5 User Manual

Tested and released DDR4 and DCPMM configurations
CPU1/2/3/4
iMC1
iMC0
Channel
Ratio
Mode
Population (DDR4:DCPMM)
(CPU1)
1F
2F
1E
2E
1D
2D
2A
1A
2B
1B
2C
1C
(CPU2)
1M
2M
1L
2L
1K
2K
2G
1G
2H
1H
2J
1J
(CPU3)
1T
2T
1S
2S
1R
2R
2N
1N
2P
1P
2Q
1Q
(CPU4)
1Z
2Z
1Y
2Y
1X
2X
2U
1U
2V
1V
2W
1W
2-2-2 (6/6)
16
128
16
128
16
128
128
16
128
16
128
16
1:8,0
All
2-2-2 (6/6) 32 128 32 128 32 128 128 32 128 32 128 32 1:4,0 All
2-2-2 (6/6) 32 256 32 256 32 256 256 32 256 32 256 32 1:8,0 All
2-2-2 (6/6) 64 256 64 256 64 256 256 64 256 64 256 64 1:4,0 All
2-2-2 (6/6) 64 512 64 512 64 512 512 64 512 64 512 64 1:8,0 All
2-1-1 (6/2) 32 32 32 128 128 32 32 32 1:1,3 1LM
2-1-1 (6/2) 64 64 64 128 128 64 64 64 1:0,7 1LM
2-1-1 (6/2) 32 32 32 256 256 32 32 32 1:2,7 1LM
2-1-1 (6/2) 64 64 64 256 256 64 64 64 1:1,3 1LM
2-2-1 (6/4) 32 32 128 32 128 128 32 128 32 32 1:2,7 1LM
2-2-1 (6/4) 64 64 128 64 128 128 64 128 64 64 1:1,3 1LM
2-2-1 (6/4) 32 32 256 32 256 256 32 256 32 32 1:5,3 All
2-2-1 (6/4) 64 64 256 64 256 256 64 256 64 64 1:2,7 1LM
1-1-1 (4/2) 128 32 32 32 32 128 1:2,0 1LM
1-1-1 (4/2) 128 64 64 64 64 128 1:1,0 1LM
1-1-1 (4/2) 256 32 32 32 32 256 1:4,0 All
1-1-1 (4/2) 256 64 64 64 64 256 1:2,0 1LM
2-2-2 (6/6)
64 128 64 128 64 128 128 64 128 64 128 64 1:2,0
1LM
2-2-2 (6/6)
16 256 16 256 16 256 256 16 256 16 256 16 1:16,0
All
2-2-2 (6/6)
128 512 128 512 128 512 512 128 512 128 512 128 1:4,0
All
2-1-1 (6/2)
16 16 16 128 128 16 16 16 1:2,7
1LM
2-1-1 (6/2)
16 16 16 256 256 16 16 16 1:5,3
All
2-2-1 (6/4)
16 16 128 16 128 128 16 128 16 16 1:5,3
All
2-2-1 (6/4)
16 16 256 16 256 256 16 256 16 16 1:10,7
All
1-1-1 (4/2) 128 16 16 16 16 128 1:4,0
All
1-1-1 (4/2) 256 16 16 16 16 256 1:8,0
All
2/1-1-1
(6/1)
32 32 32 128 32 32 32 1:0,7
1LM
2/1-1-1
(6/1)
64 64 64 128 64 64 64 1:0,3
1LM
Figure 136: Tested and released DDR4 and DCPMM configurations
Main memory
256 Upgrade and Maintenance Manual RX4770 M5
