Indication of LAN connection supporting Energy Efficient Ethernet (EEE
mode)
T
o configure the EEE mode, it is necessary that the on board LAN or an add-in
LAN card supports this mode and the connected switch supports this mode as
well.
Indicator Status Description
LAN link/
transfer
indicator
short flashing green 3x,
then of
f
A LAN connection has been
established (1 Gbit or 100 Mbit)
and EEE mode is active.
LAN speed
indicator
short flashing yellow 1x,
then 2 seconds off
green off
Data traffic at a transfer rate of
1 Gbit/s.
short flashing green 1x,
then 2 seconds off
yellow off
Data traffic at a transfer rate of
100 Mbit/s
Table 3: LAN indicators if EEE mode is active
Note on the onboard LAN controller
The system board is equipped with a Gigabit Ethernet Controller that
supports transfer rates of 100 Mbit/s and 1
Gbit/s.
The separate management LAN connector is used as a management
interface (iRMC S5) and is prepared for operation with the Remote
Management. Optionally LAN connector 1 can also be used for iRMC
S5 server management.
Appendix A
428 Upgrade and Maintenance Manual RX4770 M5
