Fujitsu PRIMERGY RX4770 M5 User Manual

Component Notes
Top/bottom system
board
no TPM, no Dual microSD 64GB Enterprise, no
M.2, no expansion card including OCP module
T
op system board without CPUs and memory
modules
2 CPUs with CPU heat
sink
installed in CPU slot 1 and 2
2 memory module one DIMM per CPU, installed in DIMM slot 1A and
1G
Front panel module
2 PSUs
Power distribution board
Table 4: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 5: Minimum startup configuration - cables
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord (AC PSU)" on page 58.
▶
Connect a display to the server.
▶
Switch on the server, see "Switching on the server" on page 59.
CAUTION
▶
Since the fan module is not included in the minimum startup
configuration, the server must be shut down immediately after the
diagnostic process is complete (POST phase has been passed).
▶
The minimum startup configuration must be used exclusively for
diagnostic purposes by maintenance personnel, never in daily
operation!
Appendix A
434 Upgrade and Maintenance Manual RX4770 M5
