Field Description
Remote Networks Displays the currently negotiated subnets of the remote termin-
al.
Security Algorithm Displays the encryption algorithm of the IPSec connection.
State Displays the operating state of the IPSec connection.
Action Enables you to change the status of the IPSec connection as
displayed.
Details Opens a detailed statistics window.
You change the status of the IPSec tunnel by pressing the button or button in the
Action column.
By pressing the button, you display detailed statistics on the IPSec tunnel.
Fig. 162: Monitoring->IPSec->IPSec Tunnels->
Values in the IPSec Tunnels list
Field Description
Description The description of the peer is displayed here.
Local IP Address The WAN IP address of your device is entered here.
Destination IP Address The WAN IP address of the connection partner is entered here.
Local ID The ID of your device for this IPSec connection is displayed
here.
Funkwerk Enterprise Communications GmbH
19 Monitoring
bintec W1002/W1002n/W2002/WIx040/WIx065 355
