Fig. 175: Monitoring -> WLAN -> WDS -><WDS Link>-> in bintec W1002n
Values in the WDS list
Field Description
WDS description Shows the name of the WDS link.
Remote MAC Shows the MAC address of the WDS link partner.
Uptime Shows the time in hours, minutes and seconds for which the
WDS link in question is active.
Tx Packets Shows the total number of packets sent.
Rx Packets Shows the total number of packets received.
Signal dBm Shows the received signal strength in dBm.
Noise dBm Shows the received noise strength in dBm.
Data Rate Mbps
Shows the current transmission rate of data received on this
WDS link in Mbit/s.
Rate Shows separately, for each of the stated data rates, the values
for Tx Packets and Rx Packets.
19.4.4 Bridge Links
In the Monitoring -> WLAN -> Bridge Links menu, the current values and activities of the
bridge links are shown.
19 Monitoring Funkwerk Enterprise Communications GmbH
368 bintec W1002/W1002n/W2002/WIx040/WIx065
